ARGO 6 WASH

Bringing you a sensation of freedom has always been one of AYRTON's most sincere

promises. For the first time in its history, AYRTON is launching a weather-sealed effects

luminaire that offers as much creative potential indoors as outside - ARGO 6 WASH.

This luminaire presents a minimalist design incorporating features for total protection

against harsh weather with easier internal access, and its front window, made of

highly resistant and exceptionally transparent polycarbonate with a V-0 protection

rating, is designed to ensure optimal visuals. The placement of pan & tilt motors in

the base and head of the luminaire avoids the constraint of weatherproofing the yoke

arms. A new submersible ventilation system in a non-waterproof compartment allows

for optimal cooling. Due to a new composite alloy, reduction in thickness of the parts,

an optimised cooling system, simplified lens guidance, and integration of low-density

optical components, AYRTON has been able to reduce overall weight by 20%.

购买咨询

下载PDF

OPTICS

• 13-element 8:1 zoom

• Beam aperture: 7° to 58°

• 148 mm frontal lens

LIGHT SOURCE

• 34,000 lumens 7000 K light engine

• Luminaire output: up to 26,000 lumens

• Colour temperature output: 6500 K

• CRI: greater than 90

• Rated life (L70): up to 40,000 hours

• Flicker-free source

MOVEMENT

•Highly accurate positioning

• Resolution: 8- or 16-bit

• Smooth movement

• Pan and tilt with automatic repositioning

• Range: 540° (pan), 263° (tilt)

COLOURS

• Sophisticated CMY colour mixing

• Variable CTO

• 6 complementary colours

GOBOS

• 7 indexable rotating HD glass gobos

•Adjustable-speed rotating gobo

• 11 fixed HD glass gobos

• Rotating gobo diameter: 27.0 mm

• Image diameter: 22.0 mm

•Gobo thickness: 1.1 mm

FRAMING SYSTEM

• 4 individual shutter blades

• Positionable on 100% of the surface area

• Rotation of the module: +/- 45°

IRIS DIAPHRAGM

• 15-blade iris diaphragm

• Range: 15% to 100% open

FROST

• 2 frost filters: one light, one heavy

PRISMS

• 2 rotating and indexable prisms

•One 5-facet circular, one 4-facet linear

EFFECTS

• Focusable graphic animation effect-wheel

• Continuous rotation in both directions

DIMMER / STROBE

• Electronic dimmer from 0 to 100%

• Strobe effect: 1 to 25 flashes per second

HARDWARE FEATURES

•Graphic LCD display with flip function

• 5 menu buttons to set the functions

• Integrated LumenRadio™ receiver

• IP65 XLR 5 pin connectors

• IP65 RJ45 connectors

• IP65 powerCON TRUE1 TOP connector

CONTROL

•DMX 512 protocol

•DMX-RDM compatible

• Stand-alone mode, local control panel

•ArtNet™ & sACN protocol

• 4 DMX modes (38 to 61 DMX channels)

POWER SUPPLY

• 100 to 240 Volts – 50/60 Hz

• Power: 800 W maximum

COOLING SYSTEM

•Advanced liquid cooling system

• IP68 Self-adjusting variable speed fans

• Selectable ventilation user modes

• Excess-temperature protection

HOUSING

• Skeleton in aluminium and steel plates

• Base in die-cast aluminium

•Moulded covers in ABS PC (V0 class)

• Two-side handles

• Four heavy-duty feet

• IP65 protection rating

• Exterior finish: black (Carbon)

INSTALLATION

• Two Omega ¼ turn brackets

• Four ¼ turn mounting points

• Safety cable attachment point

OPERATING PARAMETERS

•Maximum temperature: 45 °C (113 °F)

•Minimum temperature: -20 °C (-4 °F)

•Minimum usage distance: 2.0 m (6.56 ft)

COMPLIANCE

• EMC Directive 2014/30/EU

• LVD Directive 2014/35/EU

•US Safety: UL 1573 & FCC Part 15,

Subpart B: 2018

SIZE

• Product: 490 x 710 x 330 mm (l x h x d)

• Foam: 655 x 590 x 555 mm (l x h x d)

WEIGHT

• Product: 38.8 kg

PRODUCT CODE

• 012450: PERSEO PROFILE TC IP65

• 012452: PERSEO PROFILE TC IP66
